Standard:	TCP/IP
Sensor:	1/2.7 "
Progressive Scan CMOS
Matrix size:	8.3 Mpx
Scanning system:	Progressive
Resolution:	3840 x 2160  - 8.3 Mpx 4K UHD ,
3072 x 1728  - 5.3 Mpx ,
2560 x 1440  - 3.7 Mpx ,
1920 x 1080  - 1080p
Lens:	2.8 mm
View angle:
112 ° (manufacturer data)
100 ° (our tests result)
Range of IR illumination:	30 m
S/N ratio:	> 56 dB
RS-485 interface:
Memory card slot:	Micro SD memory cards up to 256GB support (possible local recording)
Image compression method:	Ultra 265 / H.265 / H.264 / MJPEG
Alarm inputs / outputs:
Audio:
Microphone built-in
Audio transmission via network
Audio detection
Main stream frame rate:
20 fps @ 8.3 Mpx
25 fps @ 5.3 Mpx
Network interface:	10/100 Base-T (RJ-45)
Network protocols:	IPv4/IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, IEEE 802.1x, SNMP, SSL / TLS, QoS
WEB Server:	Built-in
Max. number of on-line users:	32
ONVIF:
Mobile phones support:	Access by a cloud (P2P)
Android: UNV-Link free application
iOS (iPhone): UNV-Link free application
Default IP address:	DHCP or 192.168.1.13
Default admin user / password:	admin / 123456
Web browser access ports:	80, 554
PC client access ports:	Port no.: 80 or access by a cloud (P2P) - PC: EZStation free application
Mobile client access ports:	80
ONVIF port:	80
RTSP URL:	rtsp://192.168.1.13:554/unicast/c1/s0/live - Main stream
rtsp://192.168.1.13:554/unicast/c1/s1/live - Sub stream
Main features:
WDR - 120 dB - Wide Dynamic Range
2D-DNR, 3D-DNR - Digital Noise Reduction
F-DNR (Defog) - Reduction of image noise caused by precipitation
ROI - improve the quality of selected parts of image
ANR - Automatic Network Replenishment allows to save image to the card when the network connection with DVR is break (network failure) and next synchronize its
NAS - Network Attached Storage support
BLC/HLC - Back Light / High Light Compensation
Possibility to change the resolution, quality and bit rate
Mirror - Mirror image
Privacy zones - max. 4
Motion detection with human/vehicle silhouette recognition
Sharpness - sharper image outlines
Corridor mode - useful for monitoring corridors, entrance gates and narrow rooms
Intelligent Image Analysis : crossing the line (tripwire), intrusion, detection of entry into the area / exit from the area, face detection, people counting, crowd gathering estimation
Power supply:
PoE (802.3af),
12 V DC / 420 mA
Power consumption:	≤ 5 W
Housing:	Dome, Metal
Color:	Black
"Index of Protection":	IP67
Vandal-proof:
Operation temp:	-30 °C ... 60 °C
Weight:	0.46 kg
Dimensions:	Ø 111  x 94 mm
Supported languages:	Polish, English, Czech, Spanish, Dutch, French, German, Portuguese, Slovak, Hungarian, Italian
Manufacturer / Brand:	UNIVIEW
Guarantee:	3 years
