UMA KPRO-4 | Standalone keypad | RFID

The UMA KPRO-4 is a robust standalone keypad with an integrated RFID reader and doorbell button , suitable for both indoor and outdoor installation. The housing is made of vandal-resistant zinc-aluminum and meets the IP65 standard , making the panel highly resistant to rain, dust, and physical impact.

This keypad is designed for securely opening doors using PIN codes, RFID tags, or a combination of both , with space for up to 1000 users . The backlit keys ensure easy operation, even in the dark. The unit features a NO/NC/COM relay , a Wiegand 26 interface , and connections for an exit button and doorbell .

The KPRO-4 is powered by 12VDC (adapter not included) and is easily programmed via the keypad itself – no external software is required. For added security, the panel features an anti-tamper alarm , a status LED , and a built-in buzzer . Installation is simple thanks to its compact size and straightforward installation process.

Key Features:
✔ Standalone keypad with RFID reader (125kHz)
✔ Suitable for outdoor (IP65) and indoor use
✔ Supports 1000 users (card, code or combination)
✔ Backlit keys, LED status display
✔ NO/NC/COM relay + Wiegand 26 interface
✔ Connections for doorbell and exit button
✔ Anti-tamper detection and built-in buzzer
✔ Temperature range: -45 °C to +60 °C
✔ Dimensions: 20 x 52 x 84 mm
✔ Operates on 12VDC (power supply available separately)

You can find a suitable power supply under the Options tab. The manual is available under Documentation .
